    Z Shape Ladder Wire Mesh Belt For Fiber For Textile And Packaging Shrinking Sectors

    Ask Lasest Price
    Brand Name : Xingkuan Tech
    Model Number : Z shape Ladder wire mesh belt for fiber, textile and packaging (shrinking) sectors
    Certification : Bv ,sgs , ce , Iso
    Price : Negotiate
    Payment Terms : L/C, T/T
    Supply Ability : 5000SQM/Week
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Z Shape Ladder Wire Mesh Belt For Fiber For Textile And Packaging Shrinking Sectors

    Z shape Ladder wire mesh belt for fiber, textile and packaging (shrinking) sectors

    Descriptions :

    Suitable for a multitude of applications, this lightweight belt is energy efficient and less heat retentive in comparison to other types of belt. This particular belt has a “Z” style side finish.

    This conveyor belt, which is named as chocolate belt or washing belt as well, is usually manufactured from hard, high-carbon stainless steel material. The main preferred areas of use include chocolate coating lines, sugar-coated production, frying, cooking and cooling lines for meat/chicken (delicatessen) products. In addition, this conveyor belt is used in fiber, textile and packaging (shrinking) sectors, and frequently preferred in pastry, pizza baking lines. It has two types as single and double locked finish. It is our product, which preferred by architects for decorative purposes.

    Quick Detail :

    • Ladder conveyor belt: standard/Straight, curved
    • Speed: from less than 1 m/min to 20 m/min. (High speed quicker than 20 m/min may affect the longevity of the conveyor belt).
    • Temperature range: -100 °C to 300 °C.
    • Wire Dia:0.9mm-4.0mm
    • Rod pitch:4.0mm-19.05mm
    • Space pitch:12.7mm-25mm
    • Selvage options: Single edge, double edge,Cedge
    • Driven ways: positive driven
    • Material: Steel, Gi steel, SS304, SS316
    • Parts of specifications
    Width (mm)Pitch (mm)
    Wire Diam
    (mm)
    No. of Spaces
    Unit weight
    (Kg/LM)
    2037.261.5730.65
    3567.261.5751.05
    35612.71.8350.85
    3817.261.2770.75
    38112.71.8350.90
    4006.001.2770.95
    4006.011.2770.85
    4006.41.2750.76
    4006.401.4051.00


    Typical Applications :

    • Food Machine: convey food like Chocolate, cake,Pizza,etc
    • Widely Used in the electronics industry, the solidification of the circuit Board, solid fusion, drying, reflow soldering. Cap industry of plastic Drying; for chocolate, biscuits, fish baked, frozen and dry, with B Network edge can be used in food industry chain drive
    • fiber, textile and packaging (shrinking) sectors

    Features :

    • Easy to clean, clean-in-place design
    • No-slip, positive drive
    • Very low belt mass
    • Smallest diameter end rolls and drive rolls

    Notice :

    1. Drive: Flat Flex Belt drive by stainless steel or nylon sprocket
    2. Please send to us about your request with specificaions description or drawings
    3. Payment term: TT,LC ,or any insurance order way through other platform
    4. Delivery time : it is very fast if it is standard size .
